VCFm - Switchable Filter DIY
It´s a SMT project PANEL & PCB ONLY!!!
VCFm is a switchable multi state filter around the 2164 ic.
3 pole low pass
2 pole band pass
3 pole high pass
2 CV ins for cutoff control -5V/+5V
LED indication around the cutoff pot.
It´s a very pleasant and charming filter with very clean results.
The resonance path is not going into self oscillation, but still delivers a lot of fun.
With CV control the cutoff pot works as offset.
Find the BOM and further instructions under the guides.
